7Z71A013AU - LENOVO Thinksystem SR630 V2 1XINTEL XEON Silver

Hardware
Servers
Lenovo
Thinksystem SR630 V2 1XINTEL XEON Silver 4310 12C 2.1GHZ 120W 1X32GB 2RX8 Sw Rd 1X750W XCC Enterp...

Thinksystem SR630 V2 1XINTEL XEON Silver 4310 12C 2.1GHZ 120W 1X32GB 2RX8 Sw Rd 1X750W XCC Enterprise

Australian Stock & Warranty

All our products are Australian stock and come with a full manufacturer's warranty

Add to favourites

Please login first.

This product requires specialised freight service at an additional charge. Our sales team will be in contact with you within 1 working day of placing your order. Alternatively, feel free to contact us to receive a shipping quote

Thinksystem SR630 V2 1XINTEL XEON Silver 4310 12C 2.1GHZ 120W 1X32GB 2RX8 Sw Rd 1X750W XCC Enterprise

Network & Communication

Ethernet Technology

Gigabit Ethernet

Warranty

Limited Warranty

3 Year

Chipset

Chipset Manufacturer	Intel
Chipset Model	C621A

I/O Expansions

Number of Total Expansion Slots	2
PCI Express Details	2x LP Gen4

Storage

Optical Drive Type	No
Total Hard Drive Capacity	No

Display & Graphics

Graphics Controller Manufacturer	Matrox
Graphics Controller Model	G200
Graphics Memory Capacity	Up to 16 MB

Controllers

RAID Levels	0, 1, 5, 10, JBOD
Controller Type	Serial ATA/600
Controller Type	12Gb/s SAS
RAID Supported	Yes
Controller Model	Intel RSTe RAID

Physical Characteristics

Weight (Approximate)	26.30 kg
Form Factor	Rack
Rack Height	1U
Height	43.2 mm
Width	439.4 mm
Depth	772.2 mm

Power Description

Input Voltage	230 V AC
Input Voltage	120 V AC
Plug/Connector Type	C13/C14
Number of Power Supplies Supported	2
Number of Power Supplies Installed	1
Hot Swappable Power Supply	Yes
Maximum Power Supply Wattage	750 W

Software

Operating System	No
Operating System Supported	Windows Server 2016
	VMware ESXi 6.7 U3
	SUSE Linux Enterprise Server 15 SP2
	SUSE Linux Enterprise Server 15 SP3
	Red Hat Enterprise Linux 8.4
	Windows Server 2019
	VMware ESXi 7.0 U2
	Windows Server 2022
	VMware ESXi 7.0 U3
	Red Hat Enterprise Linux 8.2
	Red Hat Enterprise Linux 8.5
	Red Hat Enterprise Linux 7.9
	Red Hat Enterprise Linux 8.3
	SUSE Linux Enterprise Server 12 SP5

Interfaces/Ports

VGA	Yes
Number of Network (RJ-45) Ports	1
Network (RJ-45)	Yes
Remote Management	Yes
Total Number of USB Ports	6
Number of USB 2.0 Ports	1
Number of VGA Ports	1
Remote Management Controller	XClarity Controller (XCC) Enterprise

Processor

Cache	18 MB
Processor Speed	2.10 GHz
Processor Type	Xeon Silver
Processor Model	4310
Processor Core	Dodeca-core (12 Core)
Processor Manufacturer	Intel
Number of Processors Supported	2
Number of Processors Installed	1

General Information

Product Type	Server
Manufacturer Part Number	7Z71A013AU
Manufacturer Website Address	http://www3.lenovo.com/au/en
Manufacturer	Lenovo Group Limited
Product Model	7Z71A013AU
Product Name	ThinkSystem SR630 V2 7Z71A013AU Server
Product Line	ThinkSystem
Product Series	SR630 V2
Brand Name	Lenovo

Memory

Error Checking	ECC
Maximum Memory Supported	8 TB
Signal Processing	Registered (Buffered)
Standard Memory	32 GB
Memory Technology	TruDDR4
Number of Total Memory Slots	32
Number of Occupied Memory Slots	1
Intel Optane Memory Ready	Yes
Memory Clock Speed	3.20 GHz

Miscellaneous

Security Features	Chassis Intrusion Switch Power-on Password Administrator's Password Trusted Platform Module (TPM), supporting TPM 2.0
Environmentally Friendly	Yes
Environmental Certification	GREENGUARD
	EPEAT Bronze
	CECP
	RoHS
	ENERGY STAR 3.0
	CELP
Energy Star	Yes
