Thermaltake CA-1Z4-00M6WN-00- Micro-ATX- View 170 Tempered Glass ARGB- Drive Bays: 1x3.5"- 2x2.5"- Expansion Slots: 4- Motherboard support: Mini-ITX/Micro-ATX- Pre-Installed Fan: 3x120mm- Snow- 3 Year Warranty

Product ID: 429329

Vendor Code: CA-1Z4-00M6WN-00

Condition: Brand New, Sealed

^$ 80 ^.75 inc.
GST

Qty:

1 in stock

Usually ships within 24 hours

Delivery from $16.95

Enter postcode to estimate delivery fee

Overview

Enquiry

Thermaltake CA-1Z4-00M6WN-00- Micro-ATX- View 170 Tempered Glass ARGB- Drive Bays: 1x3.5"- 2x2.5"- Expansion Slots: 4- Motherboard support: Mini-ITX/Micro-ATX- Pre-Installed Fan: 3x120mm- Snow- 3 Year Warranty

Manufacturer Specifications

P/N	CA-1Z4-00M6WN-00
SERIES	View
MODEL	View 170 TG ARGB Snow
CASE TYPE	Micro Case
DIMENSION (H X W X D)	438 x 212 x 377.5 mm
DIMENSION (H X W X D)	(17.24 x 8.35 x 14.86 inch)
NET WEIGHT	6.35 kg / 14 lbs.
PANEL	3mm Tempered Glass x 2
COLOR	White
MATERIAL	SPCC
COOLING SYSTEM	Right(intake):
	120 x 120 x 25 mm ARGB Lite fan (1000rpm, 22.3 dBA) x 2

	Rear(exhaust):
	120 x 120 x 25 mm ARGB Lite fan (1000rpm, 22.3 dBA) x 1
DRIVE BAYS	1 x 3.5”, 2 x 2.5”
-ACCESSIBLE
-HIDDEN
EXPANSION SLOTS	4
MOTHERBOARDS	6.7” x 6.7” (Mini ITX), 9.6” x 9.6” (Micro ATX)
I/O PORT	USB 3.0 x 2, HD Audio x 1
PSU	Standard PS2 PSU (optional)
FAN SUPPORT	Top:
	2 x 120mm, 1 x 120mm
	2 x 140mm, 1 x 140mm
	Right:
	2 x 120mm, 1 x 120mm Rear: 1 x 120mm
	Power Cover:
	2 x 120mm, 1 x 120mm
RADIATOR SUPPORT	Top:
	1 x 240mm, 1 x 120mm
	1 x 280mm, 1 x 140mm
	Rear:
	1 x 120mm
CLEARANCE	CPU cooler max height: 160mm
	VGA max length: 340mm
	PSU max length: 180mm
